Product Details:
|
| Model Number: | RW6500DE | DC Welding Current: | 160A |
|---|---|---|---|
| Auxiliary Output: | AC 2-2.2kw | DC Welding Voltage: | 50-180 |
| Fuel Tank Capacity: | 12.5L | Fuel Type: | Diesel |
| Engine Model: | 186F | Start Method: | Electric Start |
| High Light: | 186F Diesel Welding Generators,160A Diesel Welding Generators,160A Diesel Engine Driven Welders |
||
RW6500DE Diesel Welding Generators Excitation Electric start
MOQ:24units mixed model
RW6500DE Diesel Welding Generators Excitation Electric start can be used for diesel welding and power generation, which can easily solve the problem of no power supply in field construction. We independently develop and manufacture AC power generation and DC welding motor, which adopts full copper wire winding, with sufficient power and long service life. RW6500DE Diesel Welding Generators Excitation Electric startadopts six half wave rectification technology, welding is stable, less spatter, smooth welding joint, meet the general engineering welding requirements. Ac power generation is very use all kinds of power tools on the construction site power supply, one machine dual-use cost-effective. Ac power generation DC welding, power generation voltage can be selected according to demand, widely used, suitable for a variety of scenarios, pipeline tunnel construction, field work, municipal emergency repair and other special environment has strong applicability.
Features:
• One unit, dual function
Welding and power supply at the same time.
• Supper welding
With strong air-cooled 4-stroke diesel engine, provides supper welding current.
• High conversion efficiency
100% copper alternator, class F insulation, high conversion efficiency, smart AVR controller ensures stable voltage and less voltage waveform distortion
• Safe and low fuel consumption
With new tip-clearance fuel pump and bottom inertia injection technology, security is better than that of gasoline.
• Portable design
New design of frame, compact structure, four strong wheels, easy to move.
• Multifunctional control panel
Overload Protection Device.AC generation/DC welding one-key switch.Welding current size can be fine-tuned,Digital controller to display unit frequency voltage/usage
| Model | RW6500DE |
| Rated Frequency [Hz] | 50 60 |
| Rated Voltage [V] | 220,230,240,110/220,115/230,120/240 |
| Auxiliary Output[KW] | DC/AC 2-2.2 |
| Welding Voltage Without Load [V] | 50~65 |
| Rated Current [A] | 160 |
| Work Voltage [V] | 25~30 |
| Current Regulation Range[A] | 50 ~ 180 |
| Welding Load Continuous Ration | 60% |
| Phase Number | Single Phase |
| Excitation Transistorized | Self-excitation , brush |
| Power Factor Φ | 1 |
| Insulation Grade | F |
| Fuel Tank Capacity [L] | 12.5 |
| Frame Type | 35 * 35mm Squre tube frame 35 * 35mm |
| Engine Model | RD186FAE |
| Starting System | Electric starting |
| Engine Type | 1-Cylinder ,4-Stroke, Air-cooled,Veritical |
| Broke * Stroke [mm] | 86* 72 |
| Displacement | 0.418 |
| Compression Ratio | 19.5:1 |
| Ration Rotation Speed [rpm] | 3000 3600 |
| Rated Power | 5.8 6.6 |
| Power-take-off | Crankshaft |
| Lube [L] | 1.65 |
| Fuel Type | 0#(summer), -10#(winter), Diesel oil |
| Lube | SAE10W30 ( above CD grade ) |
| Low Oil Pressure Alarm System | With |
| Overall Diemension [mm]( L*W*H) | 750*515*640 |
| Net Weight [Kg] | 116 |
