Home ProductsStick Welding Generator

160A Gas Powered Portable Stick Welder Generator 170F Arc Welder Medium Frequency

I'm Online Chat Now

160A Gas Powered Portable Stick Welder Generator 170F Arc Welder Medium Frequency

160A Gas Powered Portable Stick Welder Generator 170F Arc Welder Medium Frequency
160A Gas Powered Portable Stick Welder Generator 170F Arc Welder Medium Frequency

Large Image :  160A Gas Powered Portable Stick Welder Generator 170F Arc Welder Medium Frequency

Product Details:
Place of Origin: CHINA
Brand Name: RAMS
Certification: CE
Model Number: RWG120B
Payment & Shipping Terms:
Minimum Order Quantity: 100 units mixed model
Packaging Details: Carton/Pallet/Wooden case
Delivery Time: 25 work days
Payment Terms: T/T, L/C

160A Gas Powered Portable Stick Welder Generator 170F Arc Welder Medium Frequency

Description
Model Number: RWG120B DC Welding Current: 120A
Auxiliary Output: DC 2kw DC Welding Voltage: 22-28V
Duty Cycle At Rated Amps Avalible: 60% @120A Start Method: Recoil Start
Engine Model: 170F Fuel Type: Gasoline
High Light:

160A Gas Powered Portable Stick Welder

,

170F Gas Powered Portable Stick Welder

,

160A Generator Arc Welder

120A Petrol Welding Generators Medium Frequency Permanent Magnet Type B

MOQ:24units mixed model



Description


The 120A Petrol Welding Generators Medium Frequency Permanent Magnet Type B is designed for high power and durability. Ideal for farms, workshops, or any job that requires electrical power and CC (constant current) stick welding. Producing up to 120 Amps of DC output with a 60% duty cycle, it is suitable for welding from 6010 rods up to 6013 rods. Convenient back wheels allow for maneuverability for portable onsite welding and can also be used for emergency back-up power when necessary. Featuring incredible 7HP engine, with 2200 watts of DC output, this welder generator will provide you with the power you need wherever you need it. The 120A RWG-B Portable Petrol Welding Generators Hand Start is an excellent tool for job applications at your workshop, ranch, or farm - and is backed by a 1-year engine warranty.



Features



Hand-drawn engine fuel tank

• Able to weld 1/3, 1/4, 3/8 inch
• Permanent Magnetized Generator (PMG)
• Inverter Generator with stable sine wave for the steadiest welding
• Weld and Run Electric Tools all at once

Specifications

Brand: RAMS
Manufacturers Part Number: WG120B

Unit Specification RWG120B
DC Welding Current 120A
DC Welding Voltage 22-28V
Welding Current Range 60A-120A
Duty Cycle at rated amps avalible 60% @120A
Welding Process SMAW (MMA)
Welding Rod diameter 2.5-3.2mm
Fuel Tank Capacity 3.6L
Fuel type gasoline
Generator Specification
Axillary Output  DC 2kw
Voltage 120V/220V/240V
Dimensions&Weights
ShippingN.W/G.W 92.59Ibs/42kgs
Carton size 530*440*500mm
20.9*17.3*19.7in
Q'ty 20"/40"/40"H 200/412/515
Engine Specification
Engine Model 170F
Start Method Recoil start
Borex stroke mm 70*58
Engine type Gasoline Engine, Single Cylinder,4-Stroke,OHV,Air-Cooled

MOQ:24units mixed model

Package Includes

• WG120A Welder
• 10ft Ground Clamp
• 10ft Electrode Holder
• 8" Wheel Kit

Application

• Arc
• Stick
• MMA
• TIG
• Service Trucks
• Maintenance Crews
• Workshops
• Corrals
• Farms
• Fences
• Gates
• Ranches
• Aluminum

160A Gas Powered Portable Stick Welder Generator 170F Arc Welder Medium Frequency 0
