Product Details:
|
Model Number: | NBC-250Y | Output Current Range: | 50-250 A |
---|---|---|---|
Rated Input Power Capaity: | 9.0 KVA | Output Voltage Control Range: | 15-26.5 V |
COS Power Factor COSФ: | 0.93 | Input Voltage Frequency: | 50/60 Hz |
High Light: | 9.0 KVA Portable Welding Generators,IGBT Inverter Portable Welding Generators,IGBT Gas Welder Generator |
NBC-200Y IGBT Single Tube Gas Welding One Series Portable Welding Generators
MOQ:12units mixed model
Product Overview
The advanced digital control scheme, significantly improve the reliability of the welder, a greater degree to meet the requirements of the welding process. Using three wind way comprehensive heat dissipation, temporary load rate is high, there are all sorts of over-voltage, over-current, overheating protection function, such as the application of PWM control technology, high adaptability for electricity network. Have 2 t / 4 t function, convenient welding, improve the welding efficiency. Are widely used in various industries blank piece of metal cutting blanking, especially for iron alloy cutting.
Property Features
• IGBT inverter technology, current mode control, the quality is reliable, stable performance;
• Closed-loop feedback, constant voltage output, high adaptability for electricity network voltage (+ / - 15%)
• Electronic reactor control, stable welding process, little splash, deep pool, forming good;
• Slow wire feed, ignition of ball cutting after welding, guarantee the success rate of arc;
• Applicable thickness more than 0.8 mm in thin plate welding:
• Small volume, light weight, simple operation, economical and practical;
• A diameter of 0.6 mm wire at 30 a can realize the stable welding, which can be widely used in automobiles, steel doors and Windows, furniture and other industries:
• Cost savings, can completely replace tap welding machine;
Product Parameters
Parameters | NBC-250Y |
Input supply voltage(V) | 220 |
Rated input power capaity(KVA) | 9 |
Input voltage frequency(Hz) | 50/60 |
No load voltage(V) | 50 |
Output current range(A) | 50-250 |
Output voltage control range(V) | 15-26.5 |
Load duration rate(%) | 60 |
For wire diameter(mm) | 0.6/0.8/1.0 |
Efficiency(%) | 85 |
COS Power factor COSФ | 0.93 |
Class of insulation | F |
Weight(KG) | 20 |
Outline dimensions(mm) | 520x260x430 |
Shell protection class | IP21 |
Thrust adjusting range(A) | / |
