Product Details:
Place of Origin: CHINA
Brand Name: RAMS
Certification: CE
Model Number: RWD160DC
Payment & Shipping Terms:
Minimum Order Quantity: 100 units mixed model
Packaging Details: Carton/Pallet/Wooden case
Delivery Time: 25 work days
Payment Terms: T/T, L/C

DC 1.8kw 3.5L Single Phase Diesel Generator Medium Frequency

Description
Item: Diesel Welding Generators DC Welding Current: 160A
Auxiliary Output: DC 1.8kw DC Welding Voltage: 22-28
Welding Current Range: Unadjustable Duty Cycle At Rated Amps Avalible: 60% @160A
Fuel Tank Capacity: 3.5L Fuel Type: Diesel
High Light:

3.5L Single Phase Diesel Generator

,

1.8kw Single Phase Diesel Generator

,

1.8kw Single Phase DC Generator

140A Medium Frequency Permanent Magnet Welder Generators

MOQ:24units mixed model





Features:



• 160 apms of DC welding power
• High- frequency continuous weld 3.2mm Rod
• Can start a 2Kw air compressor
• Noise less than 75db(7m)
• Ideal for a wide variety of utility welding application
• Dry weight of only 111.33Ibs(50.5kgs) lighter much than other welders in its class
• Dry weight of only 120.15Ibs(54.5kgs) lighter much than other welders in its class

Unit Specification RWD160DC RWD160DCE
DC Welding Current 160A 160A
DC Welding Voltage 22-28V 22-28V
Welding Current Range unadjustable unadjustable
Duty Cycle at rated amps avalible 60% @160A 60% @160A
Welding Process SMAW (MMA) SMAW (MMA)
Welding Rod diameter 2.5-3.2mm 2.5-3.2mm
Fuel Tank Capacity 3.5L 3.5L
Fuel type diesel diesel
Generator Specification
Power rated output (single phrase) DC 1.6kw DC 1.6kw
Auxiliary Output(Optional) DC 1.8kw DC 1.8kw
Voltage 120V/220V/240V 120V/220V/240V
Receptacles 1ps 16A 1ps 16A
Dimensions&Weights
ShippingN.W/G.W 111.33Ibs/50.5kgs 120.15Ibs/54.5kgs
Carton size 470*520*560mm 470*520*560mm
Q'ty 20"/40"/40"H 192/400/400 192/400/400
Engine Specification
Engine Model 178F 178FE
Start Method Recoil start Electric start
Borex stroke mm 78*62 78*62
Engine type Diesel Engine,Single Cylinder,4-Stroke,Air-Cooled, Direct Injection
Ignition System Compression Ignition



MOQ:24units mixed model
